Marvin Test Solutions 社の製品を、2026年1月版の製品リストに基づいてカテゴリ別に掲載しています（全597型番）。
製品名は原文（英語）のまま記載しています。仕様・価格・納期のご確認、日本語資料のご請求はお問い合わせよりご連絡ください。
※軍事（Military）向けテストソリューション、およびポータブル／ハンドヘルド（兵装テストセット中心）は取扱対象外です。
シャーシ／コントローラ CHASSIS AND CONTROLLERS（126型番）
Chassis （89）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX7000C | 6U, 20 Slot Smart PXI Chassis with built-in DVD-RW, Hard Disk drive | |
GX7000CR | 6U, 20 Slot Smart PXI Chassis with DVD-RW, Hard Disk drive, w/Rack-Mount | |
GX7000D | 6U, 20 Slot Smart PXI Chassis | |
GX7000DR | 6U, 20 Slot Smart PXI Chassis with Rack-Mount | |
GX7002C | GX7000CR with an integrated Cable Tray & a Hinged front panel for Mass | — |
GX7002C-5FTB | 20 slot PXI Master 6U Chassis with 900 watts power & a flat front panel, card cage recessed 5", & top/bottom cable routing openings (supersedes GX7002x-5FT models) | — |
GX7002C-5TB | GX7002C with the card cage recessed 5", & top/bottom cable routing openings (supersedes GX7002x-5 models) | — |
GX7002C-MP | GX7002C with a MacPanel SCOUT Mass Interconnect Receiver | — |
GX7005C | GX7002C with additional power rails & special cooling to support High-Performance Digital Cards (GX5055 & GX5960 families) | — |
GX7005C-MP | GX7005C with MacPanel SCOUT Mass Interconnect Receiver | — |
GX7010C | 6U, 20 Slot Smart PXI Chassis for use with PXI Remote Controllers | — |
GX7010CR | 6U, 20 Slot Smart PXI Chassis for use with PXI Remote Controllers, w/rack-mount | — |
GX7012C | GX7010CR with an integrated Cable Tray & a Hinged front panel for Mass Interconnect (rackmount configuration) | — |
GX7012C-5F | 20 slot PXI Slave 6U Chassis with 900 watts power & a flat front panel, card cage recessed 5" | — |
GX7012C-5FTB | 20 slot PXI Slave 6U Chassis with 900 watts power & a flat front panel, card cage recessed 5", & top/bottom cable routing openings (supersedes GX7012x-5FT models) | — |
GX7012C-5TB | GX7012C with the card cage recessed 5", & top/bottom cable routing openings (supersedes GX7012x-5 models) | — |
GX7012C-MP | GX7012C with a MacPanel SCOUT Mass Interconnect Receiver | — |
GX7015C | GX7012C with additional power rails & special cooling to support High-Performance Digital Cards (GX5055 & GX5960 families) | — |
GX7015C-MP | GX7015C with MacPanel SCOUT Mass Interconnect Receiver | — |
GX7016 | GENASYS Switching Subsystem | |
GX7017 | GENASYS Switching / Digital Subsystem with SCOUT 6U Receiver | |
GX7100B | 6U/3U, 14 Slot Smart PXI Master Desktop Combo Chassis w/DVD-RW & Hard Disk Drive | |
GX7100B-ESATA | GX7100B Master Combo Chassis with Rear-Panel ESATA Interface | |
GX7100BR | 6U/3U, 14 Slot Smart PXI Master Rackmount Combo Chassis w/DVD-RW & Hard Disk Drive | |
GX7100e | 6U/3U, 14 Slot Smart PXIe Master Desktop Combo Chassis w/Hard Disk Drive | |
GX7100eR | 6U/3U, 14 Slot Smart PXIe Master Rackmount Combo Chassis w/DVD-RW & Hard Disk Drive | |
GX7102B | GX7100B with an Integrated Cable Tray & a Hinged Front Panel for Mass Interconnect (Rackmount Configuration) | — |
GX7102B-5TB | GX7102B with the card cage recessed 5", & top/bottom cable routing openings (formerly GX7102B-5) | — |
GX7102e | GX7100e with an Integrated Cable Tray & a Hinged Front Panel for Mass Interconnect (Rackmount Configuration) | — |
GX7102e-5TB | GX7102e with the card cage recessed 5", & top/bottom cable routing openings | — |
GX7110B | 6U/3U, 14 Slot Smart PXI Slave Desktop Combo Chassis for Use with PXI Remote Controllers | — |
GX7110B-2 | GX7110B with a 2" recessed instrument card cage (formerly GX7111B) | — |
GX7110BR | GX7110B with Rackmount | — |
GX7110BR-2 | GX7110B with a 2" recessed instrument card cage w/rack-mount (formerly GX7111BR) | — |
GX7110e | 6U/3U, 14 Slot Smart PXIe Slave Desktop Combo Chassis for Use with PXI Remote Controllers | — |
GX7110e-2 | GX7110e with a 2" recessed instrument card cage | — |
GX7110eR | GX7110e with Rackmount | — |
GX7110eR-2 | GX7110e with a 2" recessed instrument card cage w/rack-mount | — |
GX7112B | GX7110B with an Integrated Cable Tray & a Hinged Front Panel for Mass Interconnect (Rackmount Configuration) | — |
GX7112B-5FT | GX7112B with the card cage recessed 5", Top Cable Routing Opening, Flat Front Panel | — |
GX7112B-5NB | GX7112B with the card cage recessed 5", Bottom Cable Routing Opening, no door (Replaces GX7112B-5N) | — |
GX7112B-5NBT | GX7112B with the Card Cage Recessed 5", Top/Bottom Cable Routing Opening, No Door | — |
GX7112B-5NBTS | GX7112B with the Card Cage Recessed 5", Top/Bottom Cable Routing Opening, No Door, Countersink Screw | — |
GX7112B-5TB | GX7112B with the card cage recessed 5", & top/bottom cable routing openings (Formerly GX7112B-5) | — |
GX7112e | GX7110e with an Integrated Cable Tray & a Hinged Front Panel for Mass Interconnect (Rackmount Configuration) | — |
GX7112e-5NB | GX7112e with the card cage recessed 5", Bottom Cable Routing Opening, no door | — |
GX7112e-5NBT | GX7112e with the Card Cage Recessed 5", Top/Bottom Cable Routing Opening, No Door | — |
GX7112e-5NBTS | GX7112e with the Card Cage Recessed 5", Top/Bottom Cable Routing Opening, No Door, Countersink Screw | — |
GX7112e-5TB | GX7112e with the card cage recessed 5", & top/bottom cable routing openings | — |
GX7200 | 21 Slot PXIe Master Chassis | |
GX7200-MPR | 21 Slot PXIe Master Chassis, SCOUT Receiver Compatible | |
GX7200R | 21 Slot PXIe Master Chassis with Rack Mount | |
GX7201 | 21 Slot PXIe Master Chassis with Integrated mini-Computer/PXIe Thunderbolt Controller | — |
GX7202 | GX7200R with an Integrated Cable Tray and a Hinged Front Panel for Mass Interconnect (Rackmount Configuration) | — |
GX7202-I | GX7200R with an Integrated Cable Tray and iCON 960 Receiver Interface / PCB Assy | — |
GX7202-MP | GX7202 with MAC Panel SCOUT 3U receiver | — |
GX7202-N | GX7200R with an Integrated Cable Tray, (Rackmount Configuration, no door) | — |
GX7205 | 21 Slot PXIe Master Chassis with 1400W system power supply | — |
GX7205R | GX7205 Chassis with Rack Mount | — |
GX7206 | 21 Slot PXIe Master Chassis with Integrated mini-Computer/PXIe Thunderbolt controller and 1400W system power supply | — |
GX7210 | 21 Slot PXIe Slave Chassis | — |
GX7210-MPR | 21 Slot PXIe Slave Chassis, SCOUT Receiver Compatible | — |
GX7210R | 21 Slot PXIe Slave Chassis with Rack Mount | — |
GX7212 | GX7210R with an Integrated Cable Tray and a Hinged Front Panel for Mass Interconnect (Rackmount Configuration) | — |
GX7212-MP | GX7212 with MAC Panel SCOUT 3U Receiver | — |
GX7215 | 21 Slot PXIe Slave Chassis with 1400W system power supply | — |
GX7215R | GX7215 Chassis with Rack Mount | — |
GX7300C | 20 Slot 3U PXI Master Desktop Chassis w/DVD-RW & Hard Disk drive | |
GX7300CR | 20 Slot 3U PXI Master Rackmount Chassis w/DVD-RW & Hard Disk drive | |
GX7302C | GX7300CR with an integrated Cable Tray & a Hinged front panel for Mass Interconnect (rackmount configuration) | — |
GX7302C-4FTB | GX7300CR with a hinged flat front panel, card cage recessed 4", and top/bottom cable routing openings (rackmount configuration) (formerly GX7302-4FT) | — |
GX7302C-4TB | GX7300CR with the card cage recessed 4", & top/bottom cable routing openings (formerly GX7302-4) | — |
GX7302C-I | GX7302C with iCON 960 Receiver Interface / PCB Assy and Card Cage Recessed 4" | — |
GX7302C-MP | GX7302C with a MacPanel SCOUT Mass Interconnect Receiver | — |
GX7305 | 20 Slot 3U High Power/High Cooling PXI Master Chassis to Support High-Performance Digital Cards (GX5295 Family) | — |
GX7310C | 20 Slot 3U PXI Slave Desktop Chassis for use with PXI Remote Controllers | — |
GX7310CR | 20 Slot 3U PXI Slave Rackmount Chassis for use with PXI Remote Controllers | — |
GX7312C | GX7310CR with an integrated Cable Tray & a Hinged front panel for Mass Interconnect (rackmount configuration) | — |
GX7312C-4FTB | GX7310CR with a hinged flat front panel, card cage recessed 4", and top/bottom cable routing openings (rackmount configuration) | — |
GX7312C-4TB | GX7310CR with the card cage recessed 4", & top/bottom cable routing openings (formerly GX7312-4) | — |
GX7312C-MP | GX7312C with a MacPanel SCOUT Mass Interconnect Receiver | — |
GX7315 | 20 Slot 3U High Power PXI Slave Chassis | — |
GX7315R | 20 Slot 3U High Power Rack Mount PXI Slave Chassis | — |
GX7600 | 9 Slot Smart 3U PXI Express Master Chassis w/DVD-RW & Hard Disk Drive | |
GX7600R | 9 Slot Smart 3U PXI Express Master Chassis with Rackmount Kit (GX97600) w/DVD-RW & Hard Disk drive | |
GX7610 | 9 Slot Smart 3U PXI Express Slave Chassis | — |
GX7610R | 9 Slot Smart 3U PXI Express Slave Chassis with Rackmount Kit (GX97600) | — |
GX7800 | 8-Slot, 3U PXI Chassis | |
GX7800R | 8 Slot, 3U PXI Chassis with Rackmount Kit (GX97600) |
Controllers and Bus Expanders （10）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX7927-2534096 | 6U Single-Slot 2.53 GHz i7 Controller with 4 GB of Memory, Includes PMC/XMC 2 Site, 2GE, VGA, USB & COM port (FP). | |
GX7928-M | PXI Controller, 6U E-2176M Processor, 16 GB DRAM - Ruggedized / Extended Temperature | |
GX7928-SSD | PXI Controller, 6U-E2176M Processor, 16 GB DRAM w/Solid State Drive (SSD) | |
GX7938 | 3U Single Slot Embedded Controller, Intel 6-Core Xeon 2.7 GHz processor, 1 TB SSD, 32 GB DDR4 | |
GX7939 | 3U Single Slot cPCI Embedded Controller, Intel i7 Quad-core, 2.8 GHz, 1 TB SSD, 32 GB DDR4 | |
GX7951 | 11 Gen i7-1165G7 mini-PC | — |
MXI-E Thunderbolt | MXI-Express Thunderbolt Bus Expander | — |
MXI-PCIe-PXI-KIT-AD | MXI-Express Interface Kit including PCIe Interface Card, PXI Interface Card and 3 Meter Cable | — |
MXI-PCIe-X1-AD | PCI Express-to-PCI expansion card for host PC, X1 PCI Express interface - Compatible with MXI-PXI-X1-A | — |
MXI-PXI-X1-AD | PXI interface, X1 - Compatible with MXI-PCIe-X1-A | — |
Accessories / Service （27）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX7927-COM | Harlink COM Cable for GX7927 Controller | |
GX7927-VGA | Harlink VGA Cable for GX7927 Controller | |
GX7928-PSC | Peripheral splitter cable providing support for (2) USB, (2) DisplayPort, and (1) RS232 interfaces | |
MXI-E Thunderbolt-CBL-2M | MXI-E Thunderbolt-CBL-2M, Thunderbolt Cable, 2M, Active | — |
GX97003-6 | Rack Mount Kit with Handles for GX7002 / GX7012 chassis, 6U | — |
GX97005 | 3U to 6U Panel Adapter (Allows a 3U Instrument to Fit into a 6U Chassis) | — |
GX97011 | 6U Blank Panel, 1-Slot wide | — |
GX97012 | 6U Blank Panel, 2-Slots wide | — |
GX97014 | 6U Blank Panel, 4-Slots wide | — |
GX97015 | 6U Blank Panel Kit includes (3) 1-slot, (4) 2-slot and (2) 4-slot wide panels | — |
GX97024 | Replacement Power Supply for use on GX73xx Chassis Models with MRI modification 134 | — |
GX97026 | Replacement Power Supply for use on GX73x0 Chassis Models (2520-250-00) | — |
GX97028 | Replacement Power Supply for GX70xx, GX71x0B, GX73xxC, GX72x0, GX76x0 & GX7800 Chassis | — |
GX97100 | Rack mount kit for GX7100, GX7200 & GX7300 chassis | — |
GX97103 | Rack mount with Handles for GX7100 & GX7300 chassis | — |
GX97111 | 3U Blank Panel, 1-Slot wide | — |
GX97112 | 3U Blank Panel, 2-Slots wide | — |
GX97114 | 3U Blank Panel, 4-Slots wide | — |
GX97115 | 3U Blank Panel Kit includes (3) 1-slot, (4) 2-slot and (2) 4-slot wide panels | — |
GX97116 | 3U/6U Blank Panel Kit includes 3U (1) 1-slot, (1) 2-slot, (1) 4-slot and 6U (2) 1-slot & (2) 2-slot wide panels | — |
GX97117 | 3U, Single Slot, Blank Panel w/Air Baffle | — |
GX97600 | Rackmount kit for GX7600 & GX7800 chassis | — |
GX97909 | 8 & 9-Slot PXI Chassis Installation/Integration Service (Includes Chassis 2nd Year Warranty & Blank Panels) | — |
GX97914 | 14-Slot PXI Chassis Installation/Integration Service (Includes Chassis 2nd Year Warranty & Blank Panels) | — |
GX97920 | 20 / 21-Slot PXI Chassis Installation/Integration Service (Includes Chassis 2nd Year Warranty & Blank Panels) | — |
GX97921 | 20 / 21-Slot High-Power PXI Chassis Installation/Integration Service (Includes Chassis 2nd Year Warranty & Blank Panels) | — |
GX98300 | Chassis Flange Kit for SCOUT 3U Rcvr | — |
ソフトウェア SOFTWARE（84型番）
Test Executive / Test Development Software （31）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GT8000-SL | ATEasy Single User Software Package with Software License (includes 1-year subscription & support) | |
GT8000-KU | ATEasy Single User Software Package with USB Key (includes 1-year subscription & support) | |
GT8000-NL (*) | ATEasy Single User Software Package with Network License (includes 1-year subscription & support), requires a minimum of 3 licenses | |
GT8320-2Y-SL | ATEasy Single User Software Package with Software License with a 2-year Subscription and Support | |
GT8320-2Y-KU | ATEasy Single User Software Package with USB Key with a 2-year Subscription and Support | |
GT8320-2Y-NL (*) | ATEasy Single User Software Package with Network License with a 2-year Subscription and Support, requires a minimum of 3 licenses | |
GT8320-3Y-SL | ATEasy Single User Software Package with Software License with a 3-year Subscription and Support | |
GT8320-3Y-KU | ATEasy Single User Software Package with USB Key with a 3-year Subscription and Support | |
GT8320-3Y-NL (*) | ATEasy Single User Software Package with Network License with a 3-year Subscription and Support, requires a minimum of 3 licenses | |
GT8400-SBL | 1-year ATEasy Software Subscription Base License, includes Support | |
GT8000-LT | ATEasy Lite, for OEM applications. Supports unlimited OEM drivers and (2) non-OEM drivers, no executable (.EXE/.DLL) generation (includes 1 year subscription and software support). Requires a purchase of GT8000 to start. Note: Only available to OEM system manufacturers for resale of a pre-approved OEM Test System. | |
GT8003-SL | ATEasy with a 1-year Subscription and Support (Software License) and 3-day training at Marvin Test Solutions | |
GT8003-KU | ATEasy with a 1-year Subscription and Support (USB Key) and 3-day training at Marvin Test Solutions | |
GT8003-NL (*) | ATEasy with a 1-year Subscription and Support (Network License) and 3-day training at Marvin Test Solutions | |
GT8020 | 1-year Subscription and Support for ATEasy (requires continuous agreement) | |
GT8020-2Y | 2-year Subscription and Support for ATEasy (requires continuous agreement) | |
GT8020-3Y | 3-year Subscription and Support for ATEasy (requires continuous agreement) | |
GT8020-EXP24 | 1-year Subscription and Support for ATEasy, expired 7 to 24 months | |
GT8020-EXP6 | 1-year Subscription and Support for ATEasy, expired 1 day to 6 months | |
GT8029 | 1-year Support only for ATEasy (no upgrades) | |
GT98901 | Multi-Function DAQ, ATE Demo USB Board | |
GT98901-EDU | ATEasy Intro Kit with a USB ATE Demo Multi-Function Board. Academic use only. | |
GT98901-INT | ATEasy Intro Kit with a USB ATE Demo Multi-Function Board. | |
GT98901-UG | ATEasy Intro Kit User Guide | |
ATEasy-DS | 3 days ATEasy training at Marvin Test Solutions (Irvine, CA) for 1-3 persons. Call for larger groups. | |
ATEasy-DS2 | On-site, 3 days ATEasy training seminars for 1-3 persons. Call for larger groups. Note:Price does not include travel expenses. Please contact MTS for a quote | |
ATEasy-DS25 | On-site, 5 days ATEasy QuickStartTM training for 1-3 persons. Note:Price does not include travel expenses. Please contact MTS for a quote | |
ATEasy-DS5 | 5 days ATEasy training at Marvin Test Solutions (Irvine, CA) for 1-3 persons. Call for larger groups. | |
ATEasy-DSW | 3 days ATEasy Webinar training for 1-6 persons. | |
ATEasy-DSW5 | 5 days ATEasy Webinar training for 1-6 persons. | |
ATEasy-XX-YY | Replace type of ATEasy license (XX) with another (YY). Use KU, NL, or SL for XX & YY for ATEasy Subscribers -SL (Single Software License), KU (USB key), or NL (Network License, minimum 3 copies). For NL specify Qty. Also Specify the current ATEasy Serial Number. Must have current subscription. |
Digital Test Development / Debug Software （22）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
DIOEasy | Digital I/O control software including a vector generator and vector comparison | |
DIOEasy-DS | 2 days DIOEasy training at Marvin Test Solutions (Irvine, CA) for 1-3 persons. Call for larger groups. | |
DIOEasy-DS2 | On-site, 2-days DIOEasy training seminars for 1-3 persons. Call for larger groups. | |
DIOEasy-FIT | DIOEasy file import tool kit converts STIL, WGL, VCD/EVCD files to Marvin Test Solutions digital file formats for the GX529x and GX5055 digital I/O cards | |
DIOEasy-FIT-EXP24 | 1-year Renewal Expired DIOEasy-FIT Subscription and Support (expired 7 to 24 months) | |
DIOEasy-FIT-EXP6 | 1-year Renewal Expired DIOEasy-FIT Subscription and Support (expired 1 day to 6 months) | |
DIOEasy-FIT-S1Y | Renew DIOEasy-FIT Subscription and Support 1 Year (requires continuous agreement) | |
DIOEasy-FIT-S2Y | Renew DIOEasy-FIT Subscription and Support 2 Years (requires continuous agreement) | |
DIOEasy-FIT-S3Y | Renew DIOEasy-FIT Subscription and Support 3 Years (requires continuous agreement) | |
DIOEasy-FIT-SUP | 1-year Support only for DIOEasy-FIT (no upgrades) | |
DIOEasy-FIT-UG | Upgrade for DIOEasy file import tool kit | |
DtifEasy | LASAR Post Processor, Development, Run Time and Diagnostic Test Solution | |
DtifEasy-DS | 4-days DtifEasy training (includes ATEasy) at Marvin Test Solutions (Irvine, CA) for 1-3 persons. Call for larger groups. | |
DtifEasy-DS2 | On-site, 4-days DtifEasy training (includes ATEasy) seminar for 1-3 persons. Call for larger groups. | |
DtifEasy-RT | LASAR Post Processor Run Time and Diagnostic Test Solution | |
GtDio6x-FIT | Digital File Import Tool Option for GX5296 DIO | |
GtDio6x-FIT-EXP24 | 1-year Renewal Expired GtDio6x-FIT Subscription and Support (expired 7 to 24 months) | |
GtDio6x-FIT-EXP6 | 1-year Renewal Expired GtDio6x-FIT Subscription and Support (expired 1 day to 6 months) | |
GtDio6x-FIT-S1Y | Renew GtDio6x-FIT Subscription and Support 1 Year (requires continuous agreement) | |
GtDio6x-FIT-S2Y | Renew GtDio6x-FIT Subscription and Support 2 Years (requires continuous agreement) | |
GtDio6x-FIT-S3Y | Renew GtDio6x-FIT Subscription and Support 3 Years (requires continuous agreement) | |
GtDio6x-FIT-SUP | 1-year Support only for GtDiox-FIT (no upgrades) |
Analog Test Development / Debug Software （1）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
WaveEasy | Waveform development software package for GX1110/GX1120 |
Calibration Software （30）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
CalEasy | CalEasy License for all Supported Marvin Test Solutions Products (Single User License) with One Year Support and Subscription | |
CalEasy-2Y | CalEasy License for all Supported Marvin Test Solutions Products (Single User License) with Two Year Support and Subscription | |
CalEasy-3Y | CalEasy License for all Supported Marvin Test Solutions Products (Single User License) with Three Year Support and Subscription | |
CalEasy-EXP24 | 1-year Renewal CalEasy Subscription and Support (expired 7 to 24 months) | |
CalEasy-EXP6 | 1-year Renewal CalEasy Subscription and Support (expired 1 day to 6 months) | |
CalEasy-GTX2200 | CalEasy for the GTX2200 Series (Single User License) with One Year Support and Subscription | |
CalEasy-GX1034 | CalEasy for the GX1034 (Single User License) with One Year Support and Subscription | |
CalEasy-GX1110 | CalEasy for the GX1110 (Single User License) with One Year Support and Subscription | |
CalEasy-GX1120 | CalEasy for the GX1120 (Single User License) with One Year Support and Subscription | |
CalEasy-GX1164 | CalEasy for the GX1164 (Single User License) with One Year Support and Subscription | |
CalEasy-GX1632e | CalEasy for the GX1632e (Single User License) with One Year Support and Subscription | |
CalEasy-GX1649 | CalEasy for the GX1649 (Single User License) with One Year Support and Subscription | |
CalEasy-GX1838 | CalEasy for the GX1838 (Single User License) with One Year Support and Subscription | |
CalEasy-GX2065 | CalEasy for the GX2065 (Single User License) with One Year Support and Subscription | |
CalEasy-GX3104 | CalEasy for the GX3104 (Single User License) with One Year Support and Subscription | |
CalEasy-GX3116 | CalEasy for the GX3104 (Single User License) with One Year Support and Subscription | |
CalEasy-GX3348 | CalEasy for the GX3348 (Single User License) with One Year Support and Subscription | |
CalEasy-GX3722 | CalEasy for the GX3722 (Single User License) with One Year Support and Subscription | |
CalEasy-GX3748 | CalEasy for the GX3748 (Single User License) with One Year Support and Subscription | |
CalEasy-GX3788 | CalEasy for the GX3788 (Single User License) with One Year Support and Subscription | |
CalEasy-GX5055 | CalEasy for the GX5055 (Single User License) with One Year Support and Subscription | |
CalEasy-GX5295 | CalEasy for the GX5295 (Single User License) with One Year Support and Subscription | |
CalEasy-GX5296 | CalEasy for the GX5296 (Single User License) with One Year Support and Subscription | |
CalEasy-GX5960 Series | CalEasy for the GX5961 / GX5964 (Single User License) with One Year Support and Subscription | |
CalEasy-GX7400 | CalEasy for the GX7400 Series (Single User License) with One Year Support and Subscription | |
CalEasy-S1Y | Renew CalEasy Subscription and Support 1 Year | |
CalEasy-S2Y | Renew CalEasy Subscription and Support 2 Years | |
CalEasy-S3Y | Renew CalEasy Subscription and Support 3 Years | |
CalEasy-SUP | 1-year Support only for CalEasy (no upgrades) | |
CalEasy-UG | Upgrades a Single Instrument CalEasy License to Include All Supported Marvin Test Solutions Instruments |
デジタル I/O DIGITAL I/O（83型番）
Dynamic Digital I/O Instrumentation （19）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX5050-1M | Dynamic Digital I/O Master/Slave (PXI), 32 Channels up to 50 MHz w/1Mb Channel Memory and a Mating Cable. Requires one GX59XX I/O Module | |
GX5050-256K | Dynamic Digital I/O Master/Slave (PXI), 32 Channels up to 50 MHz w/256Kb Channel Memory and a Mating Cable. Requires one GX59XX I/O Module | |
GX5055 | High-Performance Digital I/O (6U), 32 ch. with 25 V swing, data formatting, and sequencer | |
GX5150 | 50MHz Digital I/O & Timing Board. 32 Channels, Master Configuration. Requires One GX59x0 I/O Module and Two or More GT500x Memory Modules | |
GX5150LV | 50MHz Digital I/O & Timing Board. 32 LV Channels, Master Configuration. Requires One GX59x0 I/O Module and Two or More GX500x Memory Modules | |
GX5151 | 50MHz Digital I/O Board. 32 Channels, Slave Configuration. Requires One GX59x0 I/O Module and Two or More GX500x Memory Modules | — |
GX5152 | 100Mhz/50MHz Digital Stim-Response (DSR) Board. 32 Channels, Master Configuration. Requires One GX59x0 I/O Module and Two or More GX500x Memory Modules | |
GX5153 | 50MHz DSR Slave Board. 32 Channels. Requires One GX59x0 I/O Module and Two or More Gx500x Memory Modules | — |
GX5282 | Dynamic Digital I/O (3U), 32 Channels up to 100 MHz w/256MB On-Board memory, w/LVDS | — |
GX5283 | Dynamic Digital I/O (3U), 32 Channels up to 200 MHz w/512MB On-Board Memory, w/LVDS | — |
GX5291-100 | Dynamic Digital I/O (3U), 32 ch. up to 100 MHz w/128MB On-Board Memory, 32-ch Domain | — |
GX5291-50 | Dynamic Digital I/O (3U), 32 ch. up to 50 MHz w/128MB On-Board Memory, 32-ch Domain | — |
GX5292 | Dynamic Digital I/O (3U), 32 ch., per Pin Control, up to 100 MHz w/256MB Memory & LVDS | — |
GX5292e | PXIe Dynamic Digital I/O (3U), 32 ch., per-pin control, 100 MHz w/256 MB memory & LVDS | |
GX5293 | Dynamic Digital I/O (3U), 16 ch., per Pin Control, up to 200 MHz w/256MB Memory & LVDS | — |
GX5295 | Dynamic Digital I/O (3U), 32 ch., per pin voltage & direction control; 100 MHz w/256 MB memory; per pin PMU | |
GX5296 | Dynamic Digital I/O (3U), 32 ch., per pin voltage & direction control; 125 MHz w/64 M Vectors per channel; per pin timing & PMU | |
GX5961 | Timing / Sync Board. Includes 16, 50MHz Digital I/O Channels | — |
GX5964A | 50MHz High Performance Dynamic Digital I/O Card. 32 Channels with 256K of Memory per Channel w/ (2) 34 pin IDC connectors | — |
Static Digital I/O Instrumentation （9）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX5641 | 64-Channel Bi-Directional TTL to RS-422 Converter, 3U PXI | |
GX5641-3 | 64-Channel Bi-Directional TTL to RS-422 Converter, 3.3V, 3U PXI | |
GX5641-XC | 62-Channel TTL to RS-422 Converter with External Control, 3U PXI | |
GX5642 | 64-Channel Bi-Directional TTL to LVDS Converter, 3U PXI | |
GX5731 | Advanced Static I/O Board supports 128 TTL I/O Channels and (3), 32 channel GX570x I/O Modules | |
GX5731-3x09 | GX5731 Advanced Static I/O Board with 224 TTL I/O Channels and 3x GX5709 I/O Interface cards | |
GX5732 | Static I/O Board with 224 TTL I/O Channels and four 8-bit Counters | |
GX5733 | 96 Channel Digital I/O with 32 Channel User Configurable I/O PXI Card | |
GX5733-GX5709 | 96 Channel Digital I/O with GX5709 I/O Interface Module, PXI Card |
Accessories / Service （55）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GT95014 | Connector Interface for GT5xxx/GX5xxx/GC5xxx, SCSI to 100 Mil Grid, Single Ended | — |
GT95015 | Connector Interface for all Gx5xxx/GX3xxx, SCSI to 100 Mil Grid, Differential | — |
GT95018 | Connector Interface Transition Board (GC/GX5050 SCSI to GT50 50-Mil Grid) | — |
GT95020 | Connector interface for GC5050/GT5050 products, SCSI to 100 Mil Grid, Single Ended (both 68 & 14 pin) | — |
GT95021 | 2 ft. shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95021E | 2 ft shielded cable for 5xxx/35xx products (68 Pin) not terminated one end | — |
GT95022 | 3 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95022E | 3 ft shielded cable for 5xxx/35xx products (68 Pin) not terminated one end | — |
GT95028 | 10 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95028E | 10 ft shielded cable for 5xxx/35xx products (68 Pin) not terminated one end | — |
GT95031 | 6 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95035E-48 | Shielded Flying Lead Cable for all 5xxx/35xx (68 Pin), 48". | — |
GT97110 | 3' cable with female DB-9 connector for GX5055 / GX5960 | — |
GX5001 | GX515x Memory Module, 1Mbx32, for 50MHz applications. 2-9 modules per GX515x | — |
GX5001-5 | GX515x Memory Module, 1Mbx32, for 50MHz applications. 2-9 modules per GX515x (Qty > 5) | — |
GX5002 | GX515x Memory Module, 2Mbx32, for 50MHz applications. 2-9 modules per GX515x | — |
GX5002-5 | GX515x Memory Module, 2Mbx32, for 50MHz applications. 2-9 modules per GX515x (Qty > 5) | — |
GX5004-40 | GX515x Memory Module, 4Mbx32, for 40MHz applications. 2-9 modules per GX515x | — |
GX5004-40-5 | GX515x Memory Module, 4Mbx32, for 40MHz applications. 2-9 modules per GX515x (Qty > 5) | — |
GX5006 | GX515x Memory Module, 256Kbx32, for 25/50MHz applications. 2-9 modules per GX515x | — |
GX5006-5 | GX515x Memory Module, 256Kbx32, for 25/50MHz applications. 2-9 modules per GX515x (Qty > 5) | — |
GX5701 | I/O Interface for GX5731 & GX5733. 32 programmable threshold input channels with 4K memory | — |
GX5702 | I/O Interface for GX5731 & GX5733. 32 TTL output channels with 4K memory | — |
GX5704 | I/O Interface for GX5731 & GX5733. 32 Open-Collector Output Channels with 4K Memory | — |
GX5709 | I/O Interface for GX5731 & GX5733. 32 differential RS-422 channels programmable in groups of 8 | — |
GX5711 | I/O Interface for GX5731 & GX5733. 16 differential LVDS inputs to TTL outputs | — |
GX5712 | I/O Interface for GX5731 & GX5733. 16 differential (RS-422) to 32 TTL channels, bi-directional | — |
GX5910 | TTL I/O Module for GX5xxx boards, 32 TTL channels at up to 50MHz | — |
GX5930 | Programmable I/OLevels and Threshold Module for GX5xxx boards | — |
GX5940 | PECL Input/output Module for GX5xxx. 32 PECL channels at up to 50MHz. | — |
GX5960 | LVDS I/O Module for GX5xxx boards, 32 differential LVDS channels at up to 50MHz | |
GX95951 | Demonstration/Training Board for GX5295 | — |
GX95961 | Diagnostic probe for use with the GX5961 | — |
GX95962 | Calibration Harness Assembly | — |
GX95963 | GX5055/GX5960 Power Cable (connects one GX5055 or GX5960 to a GX7400) | — |
GX95964 | GX5960 Calibration Software (requires additional hardware) | — |
GT95015-CAL | Connector interface board with capacitors, for calibrating GX5295 / GX5296 | — |
GX5055-5960-CALKIT | GX5055/GX5960 Calibration Cable Kit | |
GX5055-CAL | GX5055 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX5055-CAL-3 | GX5055 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX5055-CAL-5 | GX5055 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX5295-96-CALKIT | GX5295/GX5296 Calibration Cable Kit | |
GX5295-CAL | GX5295 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX5295-CAL-3 | GX5295 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX5295-CAL-5 | GX5295 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX5296-CAL | GX5296 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX5296-CAL-3 | GX5296 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX5296-CAL-5 | GX5296 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX5960A-CALKIT | GX5960A Calibration Cable Kit | |
GX5961-CAL | GX5961 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
GX5961-CAL-3 | GX5961 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX5961-CAL-5 | GX5961 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX5964-CAL | GX5964/GX5964A Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
GX5964-CAL-3 | GX5964/GX5964A Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX5964-CAL-5 | GX5964/GX5964A Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | — |
計測 MEASUREMENT（46型番）
Digital Multimeter Instrumentation （2）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX2065 | Performance 6.5 Digit DMM / Digitizer | |
GX2065-M | Performance 6.5 Digit DMM / Digitizer (Ruggedized and Conformally Coated) |
Counter Timer Instrumentation （6）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GC2210 | 225MHz PCI Time Interval Counter with 10MHz TCXO | — |
GC2220 | 1.3GHz PCI Time Interval Counter with 10MHz TCXO | — |
GC2230 | 2GHz PCI Time Interval Counter with 10MHz TCXO | — |
GTX2210 | 225MHz Time Interval Counter with 10MHz TCXO | — |
GTX2220 | 1.3GHz Time Interval Counter with 10MHz TCXO | — |
GTX2230 | 2GHz Time Interval Counter with 10MHz TCXO | — |
A/D Converters, Multi-function Instrumentation （2）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX3104 | 4 Channel SMU, ±20V, 250mA per Channel | |
GX3104-M | 4 Channel SMU, ±20V, 250mA per Channel (Ruggedized & Conformally Coated) |
Accessories / Service （36）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GT95021 | 2 ft. shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95022 | 3 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95028 | 10 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95031 | 6 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GTX2200-OCXO | A 100 ppb Oven-Controlled Crystal Oscillator for GTX2220 | |
GTX2300-OCXO | A 100 ppb Oven-Controlled Crystal Oscillator for GTX2230 | — |
GX91801 | 25 Pin Male mating connector for GX1838/GX1164/GX3104/GX7404 | — |
GX91802 | 25 Pin Male mating connector for GX1838/GX1164/GX3104/GX7404 with a 3 ft unterminated harness | — |
GX91803 | 3 feet harness for GX1838/GX1164/GX3104/GX7404, 25 pin male/female connectors on both ends | — |
GX92012 | Cable, BNC Male to BNC Male, 50 Ohm, 2' | — |
GX92015 | Cable, BNC Male to BNC Male, 50 Ohm, 5 Feet | — |
GX93005 | DIN Mating Connector for GTX22xx | — |
GX93006 | 3 ft Harness for GTX22xx/GX2065 DIN connector (DIN to Header) | — |
GC22x0-CAL | GC22x0 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
GC22x0-CAL-3 | GC22x0 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | — |
GC22x0-CAL-5 | GC22x0 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2210-CAL | GTX2210 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2210-CAL-3 | GTX2210 Calibration/Verification Service - 3 Years.Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2210-CAL-5 | GTX2210 Calibration/Verification Service - 5 Years.Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2220-CAL | GTX2220 Calibration/Verification Service Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2220-CAL-3 | GTX2220 Calibration/Verification Service - 3 Years.Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2220-CAL-5 | GTX2220 Calibration/Verification Service - 5 Years.Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2230-CAL | GTX2230 Calibration/Verification Service Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2230-CAL-3 | GTX2230 Calibration/Verification Service - 3 Years.Includes pre-verification data (post calibration data provided if applicable) | — |
GTX2230-CAL-5 | GTX2230 Calibration/Verification Service - 5 Years.Includes pre-verification data (post calibration data provided if applicable) | — |
GX2065/GX2065-M-CAL | GX2065/GX2065-M Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX2065/GX2065-M-CAL-3 | GX2065/GX2065-M Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX2065/GX2065-M-CAL-5 | GX2065/GX2065-M Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL | GX3104 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL-3 | GX3104 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL-5 | GX3104 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CALCABLE | GX3104 Calibration Cable Assembly | |
GX3788-CAL | GX3788 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CAL-3 | GX3788 Calibration/Verification Service - 3 years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CAL-5 | GX3788 Calibration/Verification Service - 5 years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CALKIT | GX3788 Calibration Cable Kit | — |
信号源／スティミュラス STIMULUS（92型番）
Arbitrary Function Generators （7）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX1110 | Single Channel DDS Function Generator/AWG, 100MS/Sec, 12-bit | |
GX1120 | Two channel AWG, 250 MS/s, 16-bit, Arbitrary Waveform Function Generator | |
GX1632e | PXIe Analog Output / Arbitrary Waveform Generator Card | |
GX1632e-M | PXIe Analog Output / Arbitrary Waveform Generator Card (Ruggedized and Conformally Coated) | |
GX1649 | Analog Output/Arbitrary Waveform Generator PXI Card | |
GX1649-1 | Analog Output/Arbitrary Waveform Generator PXI Card with Streaming | |
GX1649-M | Analog Output/Arbitrary Waveform Generator PXI Card (Ruggedized and Conformally Coated) |
Standards Source Instrumentation （9）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX1034 | Precision Reference Standards PXI Card | |
GX1034-M | Precision Reference Standards PXI Card (Ruggedized and conformal coated) | |
GX1164 | Programmable Resistor Card. 4 Channels 1 Ohm to 64 KOhm, 1 Ohm Resolution | |
GX1164-0.25 | Programmable Resistor Card. 4 channels 0.25 Ohm to 16 KOhm, 0.25 Ohm Resolution | |
GX1164-0.5 | Programmable Resistor Card. 4 Channels 0.5 Ohms to 32 KOhms, 0.5 Ohm Resolution | |
GX1164-2 | Programmable Resistor Card. 4 Channels 2 Ohm to 128 KOhm, 2 Ohm Resolution | |
GX1164-2M | Programmable Resistor Card. 4 Channels 2 Ohm to 128 KOhm, 2 Ohm Resolution (Ruggedized and Conformally Coated) | |
GX1164-4 | Programmable Resistor Card. 4 Channels 4 Ohm to 256 KOhm, 4 Ohm Resolution | |
GX1164-8 | Programmable Resistor Card. 4 Channels 8 Ohm to 512 KOhm, 8 Ohm Resolution |
Multi-function Instrumentation （5）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX3348 | 48 Channel Analog I/O Card | |
GX3348-64 | 64 Channel Analog I/O Card | |
GX3348-64M | 64 Channel Analog I/O Card (Ruggedized & Conformally Coated) | |
GX3348A | 48 Channel Analog I/O, Pulse Generator Card | |
GX3348A-64 | 64 Channel Analog I/O, Pulse Generator Card |
D/A Converters and Precision DC Source Instrumentation （12）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX1632e | PXIe Analog Output / Arbitrary Waveform Generator Card | |
GX1632e-M | PXIe Analog Output / Arbitrary Waveform Generator Card (Ruggedized and Conformally Coated) | |
GX1642 | 64 Channel 12-bit D/A, +/- 20V | |
GX1648 | 64 Channel 12-bit D/A, +/- 10V | |
GX1649 | Analog Output/Arbitrary Waveform Generator PXI Card | |
GX1649-1 | Analog Output/Arbitrary Waveform Generator PXI Card with Streaming | |
GX1649-M | Analog Output/Arbitrary Waveform Generator PXI Card (Ruggedized and Conformally Coated) | |
GX3348 | 48 Channel Analog I/O Card | |
GX3348-64 | 64 Channel Analog I/O Card | |
GX3348-64M | 64 Channel Analog I/O Card (Ruggedized & Conformally Coated) | |
GX3348A | 48 Channel Analog I/O, Pulse Generator Card | |
GX3348A-64 | 64 Channel Analog I/O, Pulse Generator Card |
Accessories / Service （59）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GT94101 | Mating connector for GT1034 / GX1034 (9 pin male) | — |
GT94102 | Mating connector for GT1034 / GX1034 with 1' harness | — |
GT94103 | Mating connector for GT1034 / GX1034 with 3' harness | — |
GT95021 | 2 ft. shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95022 | 3 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95028 | 10 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95031 | 6 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT96002 | Connector, D-Type 78-Pin Male with Crimp Pins | — |
GT96078 | 78-Pin Connector to Screw Terminal Interface | — |
GT96107 | 3 feet harness, 78 pin male connector on Both ends | — |
GT96109 | GX1649 / GX3348 Calibration Cable Assembly, 78 pin D to 78 pin D, male, 2 feet | — |
GT96110 | 5 ft Cable, 78 pin male connector on Both ends | — |
GT96111 | GX1838 Calibration Cable Assembly, 25 pin D to Dual Banana Plug, with 1K load | — |
GT96112 | GX1164 Calibration Cable Assembly, 25 pin D / 78 pin D / Dual Banana Plug | — |
GT96113 | GX1632e Calibration Cable Assembly, 78 pin D / 78 pin D / Dual Bannana Plug | — |
GT97102 | 3 ft harness, 78 pin male connector on one end, loose wires (numbered) other end | — |
GT97103 | 1 ft harness, 78 pin male connector on one end, loose wires (numbered) other end | — |
GT97104 | 1 foot harness, 78 pin male connectors on both ends | — |
GT97112 | 15' Cable, 78-Pin Male Connector on One End, Loose Wired (Numbered) Other End | — |
GT97113 | 15 ft Cable, 78 pin female connector on one end, loose wires (numbered) other end | — |
GX91801 | 25 Pin Male mating connector for GX1838/GX1164/GX3104/GX7404 | — |
GX91802 | 25 Pin Male mating connector for GX1838/GX1164/GX3104/GX7404 with a 3 ft unterminated harness | — |
GX91803 | 3 feet harness for GX1838/GX1164/GX3104/GX7404, 25 pin male/female connectors on both ends | — |
GX92012 | Cable, BNC Male to BNC Male, 50 Ohm, 2' | — |
GX92015 | Cable, BNC Male to BNC Male, 50 Ohm, 5 Feet | — |
GX93005 | DIN Mating Connector for GTX22xx | — |
GX93006 | 3 ft Harness for GTX22xx/GX2065 DIN connector (DIN to Header) | — |
GX96105 | 6 ft harness, 78 pin male connector on one end, loose wires (numbered) on other end | — |
GX96106 | 6 ft. harness, 78 pin male connector on both ends | — |
WaveEasy | Waveform development software package for GX1110/GX1120 | |
GX1034-CAL | GX1034 NIST-traceable Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX1034-CAL-3 | GX1034 NIST-traceable Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1034-CAL-5 | GX1034 NIST-traceable Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1110-CAL | GX1110 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX1110-CAL-3 | GX1110 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1110-CAL-5 | GX1110 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1120-CAL | GX1120 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX1120-CAL-3 | GX1120 Calibration/Verification Service- 3 years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1120-CAL-5 | GX1120 Calibration/Verification Service- 5 years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1164-CAL | GX1164 Calibration/Verification Service. 2 year calibration cycle. Includes pre-verification data (post calibration data provided if applicable) | |
GX1164-CAL-4 | GX1164 Calibration/Verification Service - 4 Years. Calibration Cycle is Every Two Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1164-CAL-6 | GX1164 Calibration/Verification Service - 6 Years. Calibration Cycle is Every Two Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1649-CAL | GX1649/GX1649-1/GX1649-M Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX1649-CAL-3 | GX1649/GX1649-1/GX1649-M Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1649-CAL-5 | GX1649/GX1649-1/GX1649-M Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1838-CAL | GX1838 Series Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX1838-CAL-3 | GX1838 Series Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1838-CAL-5 | GX1838 Series Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL | GX3104 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL-3 | GX3104 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL-5 | GX3104 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CALCABLE | GX3104 Calibration Cable Assembly | |
GX3348-CAL | GX3348 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX3348-CAL-3 | GX3348 Calibration/Verification Service - 3 years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3348-CAL-5 | GX3348 Calibration/Verification Service - 5 years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3788-CAL | GX3788 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CAL-3 | GX3788 Calibration/Verification Service - 3 years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CAL-5 | GX3788 Calibration/Verification Service - 5 years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CALKIT | GX3788 Calibration Cable Kit | — |
FPGA FPGA（40型番）
FPGA Cards （20）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX3500 | Flex DIO FPGA Card | |
GX3500-M | Flex DIO FPGA Card (Ruggedized and conformal coated) | |
GX3601 | FPGA PXI Card with 80 Channel TTL Buffer Module | |
GX3601-M | FPGA PXI Card with 80 Channel TTL Buffer Module (Ruggedized & Conformally Coated) | |
GX3609 | 3U FPGA PXI Card, Differential TTL, 80 Differential Channels (GX3500 & GX3509) | |
GX3610 | 3U PXI Card, mLVDS, 80 Differential Channels (GX3500 & GX3510) | |
GX3611 | 3U FPGA PXI Card, LVDS, 80 Differential Channels (GX3500 & GX3511) | |
GX3640 | 3U PXI Card, ECL, Differential Line Driver/Receiver, 40 Differential Channels (GX3500 & GX3540) | |
GX3700 | FPGA PXI High-Performance Digital I/O Card | |
GX3700-M | High-Performance, FPGA PXI Card, (Ruggedized and Conformally Coated) | |
GX3700e | 3U PXIe High-Performance FPGA Board | |
GX3702 | FPGA Card with 7811/7813 Pin-Compatible Connectors | |
GX3722 | PXI FPGA Multi-Function I/O Card | |
GX3722-M | PXI FPGA Multi-Function I/O Card - Ruggedized / Extended Temp | |
GX3756 | PXI FPGA 56 Channel TTL I/O Card | |
GX3756-M | PXI FPGA 56 Channel TTL I/O Card - Rugggedized, Extended Temp | |
GX3748 | PXI FPGA 48 - Channel Threshold Comparator Card | |
GX3748-M | PXI FPGA 48 - Channel Threshold Comparator Card - Ruggedized / Extended Temp | |
GX3788 | High-Performance, FPGA Multi-Function PXI Card | — |
GX3788-M | High-Performance, FPGA Multi-Function PXI Card, (Ruggedized and Conformally Coated) | — |
Accessories （20）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GT95015 | Connector Interface for all Gx5xxx/GX3xxx, SCSI to 100 Mil Grid, Differential | — |
GT95021 | 2 ft. shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95021R | 2 ft Shielded cable for 5xxx/35xx products (68 Pin), reversed back shell on one end | — |
GT95022 | 3 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95022E | 3 ft shielded cable for 5xxx/35xx products (68 Pin) not terminated one end | — |
GT95028 | 10 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95031 | 6 ft shielded cable for 5xxx/35xx products (68 Pin) | — |
GT95032 | 1 ft. Shielded cable with 68 Pin SCSI connectors | — |
GT95034 | 4 ft. Shielded cable with 68 Pin SCSI connectors for GX3611 / GX3610 / GX3609 | — |
GT95034-6 | 6 ft. Shielded cable with 68 Pin SCSI connectors for GX3611 / GX3610 / GX3509 | — |
GT95035E-48 | Shielded Flying Lead Cable for all 5xxx/35xx (68 Pin), 48". | — |
GX3501 | FPGA Flex Daughtercard: 80 Channel TTL Buffer | — |
GX3509 | FPGA Flex Daughtercard: 80 Channel Differential TTL | — |
GX3510 | FPGA Flex Daughtercard: 80 Channel Differential mLVDS | — |
GX3511 | FPGA Flex Daughter Card: 80 Channel LVDS Logic Compatible | — |
GX3540 | FPGA Flex Daughtercard: 40 Channel MECL | — |
GX3788-CAL | GX3788 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CAL-3 | GX3788 Calibration/Verification Service - 3 years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CAL-5 | GX3788 Calibration/Verification Service - 5 years. Includes pre-verification data (post calibration data provided if applicable) | — |
GX3788-CALKIT | GX3788 Calibration Cable Kit | — |
スイッチング SWITCHING（57型番）
Matrices, Multiplexers, RF, High Current Switching Instrumentation （25）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX6021 | RF multiplexer, 4 Groups of 1 x 4, 300MHz Bandwidth (500MHz within each group) | |
GX6115 | 15 Channel high-current relay card with 3 additional relay drivers | |
GX6125 | 25 Channel Form-C (SPDT) Relay card | |
GX6138 | 38 Channel Form-A Relay card | |
GX6377 | Multifunction Switch Card. 5 Channels 10A, 8 Channels 2A, Two 2:16 Matrix | |
GX6384-1 | Switch Matrix, Dual 32 x 2 or 64 x2 Configuration (128 cross points), 3U PXI | |
GX6384-2 | Switch Matrix, Dual 32 x 4 or 64 x 4 Configuration (256 cross points), 3U PXI | |
GX6384-3 | Switch Matrix, Dual 32 x 6 or 64 x 6 Configuration (384 cross points), 3U PXI | |
GX6188 | GENASYS High Density Matrix Switch Card, 104 x 8 x 8 | |
GX6188-M | GENASYS High Density Matrix Switch Card, 104 x 8 x 8, Ruggedized | |
GX6196 | 96 Channel DPST Relay Carrier Card | |
GX6264-C | 128 Channel Scanner/Multiplexer, Commercial Grade | |
GX6264-I | 128 Channel Scanner/Multiplexer, Industrial Grade | |
GX6315 | 45 Channel High-Current Relay Card with 9 Additional Relay Drivers | |
GX6315-M | 45 Channel High-Current Relay Card (Ruggedized and Conformally Coated) | |
GX6325 | 75 Channel Form-C (SPDT) Relay card | |
GX6325-M | 75 Channel Form-C (SPDT) Relay card ( ruggedized & conformally coated) | |
GX6338 | 114 Channel Form-A Relay card | |
GX6616 | High Density 6 x 2:16 Switch Matrix PXI Card | |
GX6616-M | High Density 6 x 2:16 Switch Matrix PXI Card (Ruggedized and conformal coated) | |
GX6032 | GENASYS Matrix Switch Rear Interface Module, 32 x 16 | — |
GX6192 | GENASYS HF MultiMatrix Switch Card, 192 x 16 x 16 | |
GX6256 | GENASYS LF 256 x 16 x 16 MultiMatrix Switch Card | |
GX6864 | GENASYS 75 Ohm RF Multiplexer Switch Card, (4) 2 x 16 Multiplexers | |
GX6062 | RF multiplexer, 12 Groups of 1 x 4, 200MHz Bandwidth |
Accessories （32）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GT96002 | Connector, D-Type 78-Pin Male with Crimp Pins | — |
GT96078 | 78-Pin Connector to Screw Terminal Interface | — |
GT96107 | 3 feet harness, 78 pin male connector on Both ends | — |
GT96108 | Connector, D-type 50 pin male with solder pins (for GX6315) | — |
GT96110 | 5 ft Cable, 78 pin male connector on Both ends | — |
GT96202 | Replacement Reed Relay for GT6064-C/GX6264-C | — |
GT96203 | Replacement Industrial Relay for GT6064-I/GX6264-I and GT1034 | — |
GT96303 | Self-Test Adapter for GT6416 and GX6616 | — |
GT96402 | Replacement RF Relay for GT6041/42 & GX6021 | — |
GT96406 | Mating Coax Connector with 20 Coax Pins crimped to 3' wires with BNCs | — |
GT97102 | 3 ft harness, 78 pin male connector on one end, loose wires (numbered) other end | — |
GT97103 | 1 ft harness, 78 pin male connector on one end, loose wires (numbered) other end | — |
GT97104 | 1 foot harness, 78 pin male connectors on both ends | — |
GT97106 | 1' harness, 50 pin male connector on one end, loose wires (numbered) other end | — |
GT97107 | 3` harness, 50 pin male connector on one end, loose wires (numbered) other end | — |
GT97108 | 1' harness, 50 pin male connectors on both ends | — |
GT97109 | 3 feet harness, 50 pin male connectors on both ends | — |
GT97112 | 15' Cable, 78-Pin Male Connector on One End, Loose Wired (Numbered) Other End | — |
GT97113 | 15 ft Cable, 78 pin female connector on one end, loose wires (numbered) other end | — |
GX96105 | 6 ft harness, 78 pin male connector on one end, loose wires (numbered) on other end | — |
GX96106 | 6 ft. harness, 78 pin male connector on both ends | — |
GX96301 | Replacement Relay for GX6315 | — |
GX96302 | Replacement Relay for GX6616 & GX6338 | — |
GX96303 | Replacement Relay for GX6325 | — |
GX96403 | Mating Coax Connector and 20 Coax Pins | — |
GX96405 | Mating Coax Connector with 20 Coax Pins crimped (both ends) to 3' wires | — |
GX96405-60 | Mating Coax Connector with 20 Coax Pins crimped (both ends) to 5' wires | — |
GX96407 | MMS pin Extraction Tool | — |
GX96408 | Burndy pin Extraction tool | — |
GX96409 | Mating Coax Connector, No Pins | — |
GX96410 | Coax connector pin for GX96409, package of 20 | — |
GX96411 | One 3' Coax wire with a Coax pin crimped on one end | — |
SMU／電源 SMUS & POWER SUPPLIES（45型番）
Power Supply Mainframe and Modules Instrumentation （2）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX7400A | 6U Power Supply Mainframe. Accepts Two Programmable Power Modules | |
GX7404 | Power Interface & Prototyping Card |
Precision DC Source Instrumentation （7）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GX1838 | Precision DC Source. 3 Voltage Rails with 8 Channels. 14-bit Resolution | |
GX1838-20 | Precision DC Source. 3 Voltage Rails (+/-20V) with 8 Channels. 14-bit Resolution | |
GX1838-20-M | Precision DC Source. 3 Voltage Rails (+/- 20V) with 8 Channels. 14-bit Resolution (Ruggedized and Conformally Coated) | |
GX1838-M | Precision DC Source. 3 Voltage Rails with 8 Channels. 14-bit Resolution (Ruggedized and Conformally Coated) | |
GX3104 | 4 Channel SMU, ±20V, 250mA per Channel | |
GX3104-M | 4 Channel SMU, ±20V, 250mA per Channel (Ruggedized & Conformally Coated) | |
GX3116e | 16 Channel Device Power Supply (DPS) |
Accessories / Service （36）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GT96002 | Connector, D-Type 78-Pin Male with Crimp Pins | — |
GT96078 | 78-Pin Connector to Screw Terminal Interface | — |
GT96107 | 3 feet harness, 78 pin male connector on Both ends | — |
GT96109 | GX1649 / GX3348 Calibration Cable Assembly, 78 pin D to 78 pin D, male, 2 feet | — |
GT96110 | 5 ft Cable, 78 pin male connector on Both ends | — |
GT96111 | GX1838 Calibration Cable Assembly, 25 pin D to Dual Banana Plug, with 1K load | — |
GT97102 | 3 ft harness, 78 pin male connector on one end, loose wires (numbered) other end | — |
GT97103 | 1 ft harness, 78 pin male connector on one end, loose wires (numbered) other end | — |
GT97104 | 1 foot harness, 78 pin male connectors on both ends | — |
GT97112 | 15' Cable, 78-Pin Male Connector on One End, Loose Wired (Numbered) Other End | — |
GT97113 | 15 ft Cable, 78 pin female connector on one end, loose wires (numbered) other end | — |
GX7415 | 0-15VDC, 10A Programmable Power Supply module for GX7400 | — |
GX7430 | 0-30VDC, 5A Programmable Power Supply module for GX7400 | — |
GX7460 | 0-60VDC, 2.5A Programmable Power Supply module for GX7400 | — |
GX91801 | 25 Pin Male mating connector for GX1838/GX1164/GX3104/GX7404 | — |
GX91802 | 25 Pin Male mating connector for GX1838/GX1164/GX3104/GX7404 with a 3 ft unterminated harness | — |
GX91803 | 3 feet harness for GX1838/GX1164/GX3104/GX7404, 25 pin male/female connectors on both ends | — |
GX96105 | 6 ft harness, 78 pin male connector on one end, loose wires (numbered) on other end | — |
GX96106 | 6 ft. harness, 78 pin male connector on both ends | — |
GX97601 | Mating connector for GX7400 | — |
GX97602 | Mating connector for GX7400 with a 6' unterminated harness | — |
GX97603 | 3' harness for GX7400, D-Type connector on Both ends (Male to Female) | — |
GX97606 | 6' harness for GX7400, D-Type connector on Both ends (Male to Female) | — |
GX97607 | 3' harness for GX7400, D-Type connector on Both ends (Male to Male) | — |
GX97608 | 6' harness for GX7400, D-Type connector on Both ends (Male to Male) | — |
GX1649-CAL | GX1649/GX1649-1/GX1649-M Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX1649-CAL-3 | GX1649/GX1649-1/GX1649-M Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1649-CAL-5 | GX1649/GX1649-1/GX1649-M Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1838-CAL | GX1838 Series Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX1838-CAL-3 | GX1838 Series Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX1838-CAL-5 | GX1838 Series Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL | GX3104 Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL-3 | GX3104 Calibration/Verification Service - 3 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CAL-5 | GX3104 Calibration/Verification Service - 5 Years. Includes pre-verification data (post calibration data provided if applicable) | |
GX3104-CALCABLE | GX3104 Calibration Cable Assembly | |
GX7400-CAL | GX7400/GX7400A Calibration/Verification Service. Includes pre-verification data (post calibration data provided if applicable) | — |
バスインターフェース BUS INTERFACES（7型番）
GPIB （3）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
GPIB-USB-HS+ | USB IEEE-488 Interface (for Windows OS) | |
PCI-GPIB | PCI IEEE-488 Interface Card (PCI Card for Windows OS) | — |
PXI-GPIB | PXI IEEE-488 interface card (3U PXI Card for Windows) | — |
Accessories （4）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
MXI-CBL-PCIe-X1-1M- AD | MXI-E x1 Copper Cable 1M | — |
MXI-CBL-PCIe-X1-3M- AD | MXI-E x1 Copper Cable 3M | — |
MXI-CBL-PCIe-X1-7M- AD | MXI-E x1 Copper Cable 7M | — |
MXI-E Thunderbolt-CBL-2M | MXI-E Thunderbolt-CBL-2M, Thunderbolt Cable, 2M, Active | — |
製造・ベンチトップシステム MANUFACTURING（17型番）
Bench Top Test Systems （9）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
TS-705A | TS-700 Basic Functional Test System | — |
TS-705As | TS-700 Basic Functional Test System (slave configuration) | — |
TS-710A | TS-700 Core Functional Test System | — |
TS-710As | TS-700 Core Functional Test System (slave configuration) | — |
TS-720A | TS-700 Core Functional Test System with JTAG Boudary Scan | — |
TS-730A | TS-700 Mixed-Signal Test System | — |
TS-750A | TS-700 Digital Test System | — |
TS-770A | TS-700 Commercial Avionics Test System | — |
TS-775A | TS-700 Military Avionics Test System | — |
Accessories （8）
| 型番 / Model | 製品名 / Description | データシート |
|---|---|---|
DIOEasy-FIT | DIOEasy file import tool kit converts STIL, WGL, VCD/EVCD files to Marvin Test Solutions digital file formats for the GX529x and GX5055 digital I/O cards | |
DIOEasy-FIT-EXP24 | 1-year Renewal Expired DIOEasy-FIT Subscription and Support (expired 7 to 24 months) | |
DIOEasy-FIT-EXP6 | 1-year Renewal Expired DIOEasy-FIT Subscription and Support (expired 1 day to 6 months) | |
DIOEasy-FIT-S1Y | Renew DIOEasy-FIT Subscription and Support 1 Year (requires continuous agreement) | |
DIOEasy-FIT-S2Y | Renew DIOEasy-FIT Subscription and Support 2 Years (requires continuous agreement) | |
DIOEasy-FIT-S3Y | Renew DIOEasy-FIT Subscription and Support 3 Years (requires continuous agreement) | |
DIOEasy-FIT-SUP | 1-year Support only for DIOEasy-FIT (no upgrades) | |
DIOEasy-FIT-UG | Upgrade for DIOEasy file import tool kit |
